제품 상세 정보:
|
| application: | Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking Water Treatment, Family Homes, Food And Beverage Industry, Hvac OEM, Industrial Boilers, Industrial Utilities, Irrigation and Ag | pressure: | Other |
|---|---|---|---|
| warranty: | 1 year | customized support: | OEM, ODM |
| power source: | Pneumatic | structure: | Diaphragm Pump |
| Warranty: | one year (except for wearing parts) | Color: | White |
| Flow rate: | 340L/M | Weight: | 22KGS |
| Model: | RV-P-B5A11-F | Keywords: | PUMP |
| Product name: | diaphragm pump | Motor: | Pneumatic |
| MOQ: | 1pc | Size: | 48*29*53 |
| 강조하다: | 1 1/2 인치 화학 저항 공기 펌프,PTFE 대막 공기유 펌프,가맹점과 함께 플라스틱 대막 펌프 |
||
최대 작업 압력 | 120psi (0.84Mpa, 8.4bar) |
최대 흐름 속도 | 90gpm ((340L/M) |
최대 역행 속도 | 200cpm |
최대 흡수 높이 (건조 흡수) | 5m |
최대 허용 곡물 | 02인치 (5mm) |
최대 공기 소비 | 80scfm ((40L/S) |
공기 입구 크기 | 1/2인치 |
공기 출구 크기 | 3/4이 |
유체 입구 크기 | 1 1/2인치 |
액체 출구 크기 | 1 1/2인치 |
무게 | 스레드 연결: PP 펌프:14KGS PVDF 펌프: 20KGS 플랜지 연결: PP 펌프: 15KGS, PVDF 펌프: 20KGS |
