제품 상세 정보:
|
| application: | Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking Water Treatment, Family Homes, Food And Beverage Industry, Hvac OEM, Industrial Boilers, Industrial Utilities, Irrigation and Ag | pressure: | Other |
|---|---|---|---|
| warranty: | 1 year | customized support: | OEM, ODM |
| power source: | Pneumatic | structure: | Diaphragm Pump |
| Warranty: | one year (except for wearing parts) | Color: | Yellow Cream |
| Flow rate: | 570L/M | Weight: | 34KGS |
| Model: | RV-P-F5A11-F | Keywords: | PUMP |
| Product name: | diaphragm pump | Motor: | Pneumatic |
| MOQ: | 1pc | Size: | 55*35*75cm |
| 강조하다: | PTFE PVDF 대막 펌프,화학적 전송 대막 펌프,공기는 이중 격판 펌프를 운영했습니다 |
||
최대 작업 압력 | 120psi (0.84Mpa, 8.4bar) |
최대 흐름 속도 | 150gpm ((570L/M) |
최대 역행 속도 | 145cpm |
최대 흡수 높이 (건조 흡수) | 5m |
최대 허용 곡물 | 0.24min (6mm) |
최대 공기 소비 | 140 sqm ((70L/S) |
공기 입구 크기 | 1/2인치 |
공기 출구 크기 | 3/4이 |
유체 입구 크기 | 2인치 |
액체 출구 크기 | 2인치 |
무게 | 플랜지형 PP 펌프: 31KGS, PVDF 펌프: 33 KGS |
